Combi 748 SE
Petrol lawn mower
Self-propelled lawn mower with 139 cc petrol engine and electric start. 4-in-1 cutting system: collection, mulching, side discharge and rear discharge. 60 litre collector.
- 139 cc STIGA petrol engine with Electric Start
- Self-propelled
- 46 cm cutting width
- 60 litre grass collector with grassbag full indicator
- 4-in-1 cutting system: collection, mulching, side discharge and rear discharge modes
Product details and specs
The self-propelled STIGA Combi 748 SE lawn mower has a 46 cm cutting width and a 60 litre hybrid grass collector with grassbag full indicator. The steel chassis houses a reliable 139 cc STIGA ST 140 LS engine with a net power output of 2.20 kW @ 2900 rpm and a handy electric start button for the lithium battery. The Combi 748 SE lets you choose from 4 different functions: rear discharge, side discharge, collection or mulching, which finely shreds the clippings and deposits them on the ground to fertilise the soil. The centralised cutting height is easily adjusted with a lever to 6 different positions, ranging from 22 to 80 mm. The large (280 mm) rear wheels make it easy to manoeuvre on uneven terrain. Side deflector and mulching plug included. The grass collector has an attachment to easily connect it to the machine and to avoid loss of grass cuttings when removing it.
Technology
STIGA engines (petrol)
STIGA petrol engines are the power behind a whole range of machines – from lawn mowers and tractors to swift-to-start sweepers. Meticulously designed and rigorously tested – only the ones with maximum performance and minimum emissions make the cut.
Fulcrum
Specially engineered for STIGA lawn mowers, our Fulcrum handlebar completely reinvents your relationship with cutting your lawn. Innovative in design, it can be angled up to 25° away from the deck – allowing you to mow under hedges and along walls without getting scratched, scuffed or dirty. Easy to assemble, adjust, use and store.
STIGA engines with electronic start
STIGA offers a complete range of engines equipped with Li-Ion start and developed specifically for lawn mowers. These engines are equipped with a completely new battery system for electric start, which makes the engines more reliable, even at very low temperatures. All batteries have over 12 months storage time with at least 50% remaining. You can enjoy up to 200 starts per charge, with 20 times less energy consumption in static mode. This enhances the user experience and increases the engines’ reliability.
What's in the box
Combi 748 SE
Petrol lawn mower- lensGrass bag
- lensMulching plug
- lensSide deflector
- lensPin for rear discharge
- lensBattery
- lens Battery charger
Technical specs
General info
Lineup
Combi
SKU
2L0486548/ST2
EAN/UPC
8008984852006
Level
Experience
Series
Series 7
Power
Power
2.2 kW
Power source
Petrol
Engine Brand
STIGA
Engine model
ST 140 LS OHV Autochoke Powered by STIGA
Displacement
139 cm³
Engine rotation speed
2900 rpm
RPM control
Fixed rpm
Starter
Electric start by button
Fuel tank capacity
0.9 l
Engine Oil tank capacity
0.5 l
Suggested working area
1200 ㎡
Cutting system
4 in 1 cutting system
Yes
Cutting width
46 cm
Deck material
Galvanized steel
Cutting height adjustment
Centralized
Cutting height positions
6 positions
Cutting height range
22 - 80 mm
Drive system
Driving
Self-propelled
Traction
Rear-wheel drive
Speed forward
3.7 Km/h
Equipment
Collector capacity
60 l
Handlebar type
Fulcrum + soft grip
Wheels
200/280mm grooved wheels on ball bearings with soft tread
Front handle
Yes
Adjustable handlebar
Yes
Foldable handlebar
Yes
Washing link
Yes
Collector type
Hybrid with warn
Vibration and noise data
Guaranteed sound power level (LwA) - dB(A)
96
Measured sound power level dB(A)
96
Measured sound pressure level at operator ear dB(A)
83
Vibration level hand (m/s2)
5.9
Overall dimensions
Pack weight
38.4 kg
Product length
1510 mm
Product width
530 mm
Product height
1200 mm
Product weight
34 kg
Related Accessories
Support
Should the petrol lawn mower be protected from rain?
All STIGA lawn mowers are IPX4 certified, meaning that they are not damaged by rain. However, it is recommended to keep the lawn mower in a garage or store it indoors. Full information can be found in the instruction manual.
Is this petrol lawnmower already assembled in the box?
The petrol lawn mower is almost fully assembled when you open the box. The main parts have been put together and the remaining elements are easy to assemble. Follow the directions in the instruction manual to ensure the petrol lawnmower is assembled correctly.
Is the instruction manual in the box for this petrol lawnmower?
The instruction manual is included in the box of this petrol lawn mower. The instruction manual can also be viewed or downloaded from the STIGA website, accessible from the "Manuals" section of the product page.
Which fuel and engine oil are recommended for this petrol mower?
You should use petrol as fuel. In terms of engine oil, we recommend using the specific STIGA oil, which can be purchased separately. This will guarantee the best engine performance and optimal lubrication.
What cutting deck height is recommended for the mulching function on this petrol mower?
The mulching system allows you to cut the grass into fine pieces, which remain on the lawn, restore nutrients and support growth.
To use this function, turn off the engine, remove the bag, insert the mulching plug provided and set the chassis height so that the grass will be cut to a length that does not exceed a third of the total grass height of the lawn.
To use this function, turn off the engine, remove the bag, insert the mulching plug provided and set the chassis height so that the grass will be cut to a length that does not exceed a third of the total grass height of the lawn.
How should the oil level be measured on this petrol lawn mower?
To correctly measure the oil level, you need to make sure the petrol lawnmower is on a flat surface, unscrew the cap which has a built-in dipstick for measuring, clean off any oil on the dipstick and reinsert it without screwing it in. Take the dipstick back out and check the level, which must lie between the MIN and MAX values. Top up, if required, and screw the cap back on. Full details can be found in the engine manual.
How to assemble the new STIGA handlebar: the Fulcrum
How to adjust the height of the new STIGA handlebar - the Fulcrum
How to fold the new STIGA handlebar - the Fulcrum - for storage
How to rotate the new STIGA handlebar - the Fulcrum - while in use
How to fix and adjust correctly the Fulcrum handlebar
