Combi 748e V Kit
Battery lawn mower
Quick, comfortable and lighter on the environment. That's the Combi 748e V lawn mower. Plus, with an intuitive keypad featuring a six-speed variator and eco mode; 4-in-1 cutting system; and adjustable and foldable handlebar, you'll be in complete control of your machine. Batteries & charger included.
- New Fulcrum handlebar – set the height and angle as you cut.
- Adjustable handlebar with keypad, including six speeds and eco mode.
- Flexible 4-in-1 cutting system.
- Hybrid 60l grass catcher.
- 46cm Combi cutting deck with ultra-durable galvanised deck.
- 2 x STIGA ePower (7.5 Ah) and charger included.
- Battery kit included
Product details and specs
Fast, robust and powerful, this smart battery lawn mower gives you stress-free, cord-free performance. Featuring a durable 46cm galvanised metal deck, it covers lots of ground with minimal effort. And its extra-powerful 1.5kW brushless motor provides efficient, comfortable mowing – consuming 30% less energy than a brushed equivalent.
Your advanced cordless lawn mower is designed for convenience too. The Combi 748e V's intuitive keypad lets you choose between six speeds and an eco mode, while its 4-in-1 cutting system offers six cutting height choices. To match your lawn and season, you can decide whether to mulch, collect, side or rear discharge. And you can adjust the handlebar to your height. The front also features strong protection from impact, and a carry handle for easy lifting.
Your advanced cordless lawn mower is designed for convenience too. The Combi 748e V's intuitive keypad lets you choose between six speeds and an eco mode, while its 4-in-1 cutting system offers six cutting height choices. To match your lawn and season, you can decide whether to mulch, collect, side or rear discharge. And you can adjust the handlebar to your height. The front also features strong protection from impact, and a carry handle for easy lifting.
Features
Redesigning the way, you mow.
Specially engineered for STIGA walk-behind mowers, our Fulcrum handlebar completely reinvents your relationship with cutting your lawn. Innovative in design, it can be angled up to 25° away from the deck – allowing you to mow under hedges and along walls without getting scratched, scuffed or dirty.
Control at your fingertips.
The handlebar-mounted keypad gives you added control. Check your battery status, choose between six speeds, and switch to eco mode.
60l grass catcher for extra capacity
With 60l storage, the Combi 748e V has plenty of space for mowing larger gardens. Which means less time spent emptying and more enjoying the experience.
Technology
STIGA ePower
Smart, safety tested and synched with STIGA products, ePower is the next generation in batteries. Tests we run on ePower batteries are 5 times tougher than Industry standard requirements, to ensure the highest quality standards in terms of performance, reliability and battery health through time. Our batteries are efficient, as we optimised and secured the position of each individual cell; safe, as we created space to allow air to cool; and smart, as we we developed and tested the electronics and software that controls the cells.
Fulcrum
Specially engineered for STIGA lawn mowers, our Fulcrum handlebar completely reinvents your relationship with cutting your lawn. Innovative in design, it can be angled up to 25° away from the deck – allowing you to mow under hedges and along walls without getting scratched, scuffed or dirty. Easy to assemble, adjust, use and store.
What's in the box
Combi 748e V Kit
Battery lawn mower- lensGrass bag
- lensMulching plug
- lensSide deflector
- lensPin for rear discharge
- lens2 Batteries
- lensBattery charger
Technical specs
General info
Lineup
Combi
SKU
2L0487978/ST1
EAN/UPC
8008984860612
Level
Experience
Series
Series 7, ePower 48 V
Power
Battery capacity
2 x 7.5 Ah
ePower
Yes
Power
1.5 kW
Power source
Battery
Voltage
48 Volt
Battery kit
Included
Lithium battery nominal energy
648 Wh
Number of batteries
2
Suggested working area
1050 ㎡
Cutting system
4 in 1 cutting system
Yes
Cutting width
46 cm
Deck material
Galvanized steel
Cutting height adjustment
Centralized
Cutting height positions
6 positions
Cutting height range
22 - 80 mm
Eco-mode
Yes
Drive system
Driving
Self-propelled with electronic speed variator
Traction
Rear-wheel drive
Speed forward
2.5-5 Km/h
Equipment
Collector capacity
60 l
Handlebar type
Fulcrum with keypad + soft grip
Wheels
200/280mm grooved wheels on ball bearings with soft tread
Front handle
Yes
Adjustable handlebar
Yes
Foldable handlebar
Yes
Collector type
Hybrid with warn
Tools kit
Battery charger
Dual standard
Battery charger plug type
Europlug (Type C)
Vibration and noise data
Guaranteed sound power level (LwA) - dB(A)
95
Measured sound power level dB(A)
94.36
Measured sound pressure level at operator ear dB(A)
82.4
Vibration level hand (m/s2)
< 2.5
Overall dimensions
Pack weight
39 kg
Product length
1510 mm
Product width
530 mm
Product height
1200 mm
Product weight
30 kg
Support
How does Eco Mode work on battery lawn mowers?
The Eco Mode function, easily activated by a button near the display on the handle of battery lawn mowers, reduces the engine’s number of rotations per minute. When the grass is not especially high, and so maximum net power output is not required, Eco Mode saves battery power for the cordless lawn mower and guarantees maximum battery life.
How should this battery lawn mower be cleaned after use?
We recommend cleaning the grass cutter of this cordless lawn mower in the normal way after each use. Before washing the grass cutter, we suggest that any residual grass or top soil is removed using the special STIGA scraper, which can be purchased separately.
Next, the inside of the chassis can be washed with water: connect the hose pipe to the washing link and follow the steps described in the user manual.
Next, the inside of the chassis can be washed with water: connect the hose pipe to the washing link and follow the steps described in the user manual.
How do I use the safety key on this cordless lawn mower? Where can I find it?
The safety key, which can be found inside the battery compartment of your cordless lawn mower, comes with the grass cutter. The key is required to turn on the battery lawn mower and must be removed after use for safety reasons.
What is the cutting height of this battery lawn mower set to?
The cutting height of your battery lawn mower can be adjusted according to desired grass length. If the grass is very long, we recommend first mowing the lawn with the cutting deck of your battery mower in a higher position. Then, mow the lawn a second time with the cutting height set to the desired grass length. For information on cutting height positions of your battery mower, refer to the "Technical specs" section. Read the instruction manual of your cordless lawn mower carefully.
What cutting deck height is recommended for the mulching function on this cordless lawn mower?
The mulching system allows you to cut the grass into fine pieces, which remain on the lawn, restore nutrients and support growth. To use this function, the height of the chassis must be set so that the grass will be cut to a length that does not exceed a third of the total grass height of the lawn.
Can this battery lawn mower run on battery power as well as with a power cable?
The cordless mower can run on battery power only, using a compatible battery or batteries.
How to assemble the new STIGA handlebar: the Fulcrum
How to adjust the height of the new STIGA handlebar - the Fulcrum
How to fold the new STIGA handlebar - the Fulcrum - for storage
How to rotate the new STIGA handlebar - the Fulcrum - while in use
How to fix and adjust correctly the Fulcrum handlebar
5 videos
